07100/07196 Imperial Tapered Roller Bearing
- Standard 1-Inch Bore: Fits standard 25.4 mm shafts without additional sleeve adapters.
- Slim Outer Envelope: Compact 13.495 mm width allows for low-profile machine designs.
- High Rigidity: Optimized roller-to-raceway contact line handles dynamic combined loads effectively.
- Long Fatigue Life: Micro-clean steel reduces internal material impurities to prevent premature flaking.
Technical Data
| Technical Parameter | Metric Value |
| Inner Bore Diameter (d) | 25.400 mm |
| Outer Diameter (D) | 50.005 mm |
| Total Width (T) | 13.495 mm |
| Precision Standard | ABEC-1 / P0 |
Product Specifications
| Specification | Details |
| Item Type | Compact Imperial Tapered Roller Bearing |
| Model Number | 07100/07196 (Cone: 07100 / Cup: 07196) |
| Bearing Design | Single Row Tapered |
| Material | Premium GCr15 Steel |
| Cage Material | Stamped Steel |
Product Introduction
The 07100/07196 is a popular 1-inch bore tapered roller bearing engineered for compact mechanical systems requiring high load density. Sized at 25.4 x 50.005 x 13.495 mm, this assembly combines a 25.4 mm (1-inch) bore cone with a slim 50.005 mm cup width profile. Manufactured using premium GCr15 bearing steel, it delivers reliable operational precision, high radial stiffness, and effective thrust resistance in space-restricted mechanical housings.
Applications
Small engine power take-off (PTO) shafts.
Conveyor drive pulleys and roller ends.
Automotive steering pinions and gear assemblies.
FAQ
Q: What is the main application of the 07100/07196?
A: It is widely used in automotive steering gears, light gearboxes, and small industrial drives needing a 1-inch inner bore.
Q: Is sample testing available before placing volume orders?
A: Yes, we provide sample shipments for OEM qualification and performance testing.
OEM & Custom Service
Bespoke manufacturing services including customized laser etching, specialized low-noise greasing, and customized box artwork.
Packing & Delivery
Coated in industrial rust preventative oil, sealed in VCI barrier material, boxed individually, and loaded on heat-treated export pallets.
