23948CA/W33 Heavy-Duty Spherical Roller Bearing 240x320x60mm
- Self-Aligning Capability: Accommodates angular shaft misalignment caused by heavy loading or frame flex without increasing internal friction.
- Solid Brass Cage (CA): Machined brass guidance provides superior strength, thermal stability, and wear resistance under intense shock loads.
- W33 Lubrication Feature: Built-in outer ring oil groove and lubrication holes facilitate straightforward maintenance and smooth grease/oil replenishment.
- Manual Assembly & Alignment: Skilled manual positioning ensures proper roller retention, matched clearances, and smooth rotation prior to shipment.
Technical Data
| Technical Parameter | Metric Value |
| Inner Bore Diameter (d) | 240.00 mm |
| Outer Diameter (D) | 320.00 mm |
| Width (B) | 60.00 mm |
| Precision Standard | ISO P0 / ABEC-1 |
Product Specifications
| Specification | Details |
| Item Type | Heavy Spherical Roller Bearing |
| Model Number | 23948CA/W33 |
| Material | Top-Tier GCr15 Chrome Steel |
| Dimensions (Metric) | 240.00 mm x 320.00 mm x 60.00 mm |
| Cage & Feature | Machined Brass Cage (CA) / Lube Groove & Holes (W33) |
Product Introduction
The 23948CA/W33 is a large-bore, high-capacity spherical roller bearing designed for demanding industrial machinery operating under severe radial loads and heavy shaft deflections. Featuring a 240 mm inner bore, 320 mm outer diameter, and a 60 mm total width, this model incorporates a heavy-duty "CA" machined brass cage and a "W33" annular lubrication groove with three lube holes on the outer ring. Heat-treated to deliver superior fatigue resistance, the 23948CA/W33 provides self-aligning capability to handle structural misalignment in heavy industrial drive systems, steel mills, and mining crushers.
Applications
Steel mill roll stands, continuous casters, and heavy forging equipment.
Mining machinery, jaw crushers, vibratory screens, and ball mills.
Industrial speed reducers, heavy gearboxes, and paper mill machinery.
FAQ
Q: What does the "CA/W33" suffix stand for?
A: "CA" indicates a one-piece double-pronged machined brass cage with retaining flanges; "W33" indicates an annular lubrication groove with three lube holes in the outer ring.
Q: How is this heavy industrial bearing protected for ocean freight?
A: Given its 240x320x60mm frame size, each bearing is thoroughly greased, sealed in heavy VCI anti-rust barrier film, and bolted inside an individual reinforced wooden case.
OEM & Custom Service
B2B services include custom clearance configurations (e.g., C3/C4), custom laser serialization, bespoke wooden box packaging, and containerized export handling.
Packing & Delivery
Coated with heavy-duty anti-corrosion grease, vacuum-sealed in VCI barrier film, housed in a custom reinforced wooden crate, and palletized for safe ocean shipping.
